Förpackning: Bulk
- USB type C connector supports particularly fast data and video transmission at up to 10 Gbit/s
- UHD-capable with resolutions of up to 4K @ 60 Hz (3840 x 2160 pixels)
- Extremely versatile, e.g. to connect 2x USB-C™ cables and extend your connection or as a Keystone jack in a distribution panel, wall socket or desk insert
- Practical solution for the office, hotel or even conference room with structured cabling to connect projectors, notebooks and smartphones
- The Keystone jack adapter with a female to female connection is attached to the patch panel or chassis by snap-in mounting.
- Suitable for USB Power Delivery up to max. 5 A/100 W and a rated voltage of 5-20 V at 5 A rated current in standard operation
- USB-C™ coupler with SuperSpeed USB 10Gbps, backwards compatible with Hi-Speed USB and USB 3.2 Gen 1 SuperSpeed USB 5Gbps
Output, max. amperage: 5.0 A
Output, voltage (DC): 20 V (DC)
Output, voltage (DC): 20.0 V (DC)
Markings: WEEE, CE
Height: 16.1 mm
Length: 28.8 mm
Operating temperature up to: 45 °C
Operating temperature from: 0 °C
Width: 17.2 mm
max. performance: 100.0 W
Output current: 5 A
Output voltage: 15.0 V
max. transmission rate: 10 Gbit/s
construction form: Keystone grid (14,9 x 17,0 mm)
4040849612626EAN:
