DeLOCK Thunderbolt 3 cable, 0.5m, 40Gbps, USB-C, up to 100W, Cypress E-marker Chipset, 4096x2160 at 120Hz, cascadable, black
This Thunderbolt 3 cable by Delock is universally applicable and combines all the advantages of the Thunderbolt 3 interface. It allows the connection of different devices such as external enclosures, monitors, card readers and docking stations via a Thunderbolt 3 port of a PC or laptop. The cable provides data transfer rates of up to 40 Gb/s and supports USB, Displayport, PCI Express as well as Ethernet data transfer. The connection of one 5K or two 4K Displayport monitors is possible, as is the connection of USB 3.1 Gen 2 devices. Furthermore the cable enables the power supply of connected devices with up to 100 W.
Specification
• Connector:
1 x Thunderbolt 3 USB-C 24 pin male >
1 x Thunderbolt 3 USB-C 24 pin male
• Chipset: Cypress E-Marker
• Cable gauge:
32 + 34 AWG data line
24 + 34 AWG power line
• Cable diameter: ca. 4.4 mm
• Conductors: 8 x coaxial for SuperSpeed USB, 1 x Twisted Pair for USB 2.0
• Gold-plated connector
• Triple shielded cable
• Data transfer rate:
Thunderbolt 3 up to 40 Gb/s
Displayport 1.2a up to 21.6 Gb/s
SuperSpeed USB up to 10 Gb/s
Thunderbolt Networking up to 10 Gb/s (Peer-To-Peer)
• Display resolution up to:
1 x 5120 x 2880 30 Bit at 60 Hz,
1 x 4096 x 2160 30 Bit at 120 Hz or
2 x 4096 x 2160 30 Bit at 60 Hz
(depending on the system and the connected hardware)
• Supports data and video on a single cable
• Supports PCI Express 3.0 protocol (4 lanes)
• Supports Displayport 1.2a protocol (8 lanes, HBR2 and MST)
• Daisy Chain up to 6 Thunderbolt™ devices (cascadable)
• Dual channel, bi-directional data transfer
• Power supply via USB Power Delivery up to 100 W (20 V / 5 A)
• Power supply for Thunderbolt™ 3 devices with bus power (max. 15 W)
• Colour: black
• Length without connector: ca. 0.5 m
System requirements
• PC or laptop with a free Thunderbolt 3 port
Package content
• Thunderbolt cable
Package
• Retail Box
