The Elite 500 is a good solution for optimised cooling where front panel ventilation allows fresh air to enter the system in both air and liquid cooled configurations. It is also a cost-effective solution for professional applications where a liquid cooler and the largest graphics cards can be installed. The front panel has a large grille for air intake and the enclosure can accommodate up to six fans and a radiator in the front, top and rear. The power supply shield cable is vented so that the components to be cooled can be mounted with the fan up or down, allowing the installation of a passively cooled power supply.
The case can accommodate graphics cards up to 350 mm long and processor coolers up to 161 mm high. The hard disk drive (HDD) is removable, allowing the installation of a larger power supply.
Features
- Motherboard support: ATX, Mini-ITX, Micro-ATX
- Size: midi-tower
- Material: steel, plastic
- 5.25" slots: 0 slots
- 2.5"/3.5" slots: 2 pcs
- 2.5" SSD slots: 3 pcs
- Front panel connections: 2 x USB 3.2 Gen 1 Type-A, 1x 3.5 mm audio jack (audio+mic)
- Expansion slots: 7
- Power supply support: ATX, at the bottom
- Maximum height of processor cooler: 163 mm
- Maximum length of the display driver: 350 mm
- Maximum power supply depth: 160 mm
- Dust filters: ceiling, front and bottom
- Dimensions: 409 x 204 x 455 mm
- Supplied with one pre-installed 120 mm fan
- Two-year warranty
Fan positions:
- 3 x 120 mm / 2 x 140 mm at the front
- Ceiling 2 x 120 mm / 2 x 140 mm
- Rear 1 x 120 mm
Cooling support:
- Front 120 / 140 / 240 / 280 / 360 mm
- Ceiling 120 / 240 mm
- Rear 120 mm
- Large air intakes in the front panel
- Steel side panel
- ATX enclosure
- Removable hard disk drive cage
