Fortunately, it has inherited the size and format of its predecessors, so (almost) all hats, boxes and accessories for the 3B also fit it.
The changes we see mainly in the new processor clocked at 1.4GHz, upgraded network connections and the possibility of power supply via the network port, Power over Ethernet or PoE (requires PoE module). The wireless network operates at both 2.4 and 5GHz and is now modularly certified, simplifying testing and certification for end products that integrate Raspberry Pi.
Processor / Memory:
* Broadcom BCM2837B0, Cortex-A53 64-bit SoC @ 1.4GHz
* 1GB LPDDR2 * microSD card reader for operating system and data storage
Connections:
* Gigabit Ethernet over USB 2.0 (max 300Mbps)
* WiFi 2.4GHz and 5GHz IEEE 802.11 b/g/n/ac
* Bluetooth 4.2 BLE
* 4x USB 2.0
Audio / Video:
* HDMI
* MIPI DSI display port
* MIPI CSI camera port
* Stereo audio + composite video (4-pin 3.5mm connector)
GPIO:
* 40-pin (2x20) pin strip 2.54mm pitch
* I2C, SPI, I2S, UART, 3.3V, 5V
Power supply:
* 5V/2.5A via microUSB
* 5V via GPIO connector
* 36 - 56V via Power over Ethernet (requires PoE module)
Dimensions:
* 85 x 56 x 16mm
* mounting holes c-c 58 x 49mm ø2.75mm
