Omada 4G+ Cat6 AX3000 Gigabit VPN Router ER706W-4G
Support 4G+ Cat6: Insert a Nano SIM card to enjoy up to 300 Mbps.**
AX3000 Dual-Band WiFi 6: Supports 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz*
6 Gigabit Ethernet Ports: Provide high-speed wired connectivity.
5 High-Gain Detachable Antennas: Extend and concentrate the Wi-Fi signals.
Centralized Management: Cloud access and the Omada app for easy management.
Omada Mesh: Seamlessly connects to EAPs that support mesh technology.*△
High-Security VPN: Supports IPSec / SSL / WireGuard / OpenVPN / PPTP / L2TP VPN.△
*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and coverage are not guaranteed and will vary.
**Actual 4G downlink speeds vary between buildings. Factors affecting 4G speeds include the internet service plan, real-time network capacity, equipment and client limitations, and environmental factors.
*△Omada Mesh Technology requires the use of EAPs that support mesh functionality. Please refer to https://www.tp-link.com/en/omada-mesh/product-list/ to confirm which Omada EAPs are compatible with Omada Mesh. Additionally, ER706W-4G also supports standalone mesh. Please refer to https://www.tp-link.com/en/standalonemesh/product-list/ to confirm the specific models.
‡Use of WiFi 6 (802.11ax) and its features, including OFDMA, HE160, and 1024-QAM, requires clients to support the corresponding features. The 160 MHz bandwidth is only available on the 5 GHz band. It may be unavailable in some regions or countries due to regulatory restrictions.
△For PPTP VPN and L2TP VPN, ER706W-4G can connect with up to 10 VPN servers. For OpenVPN, ER706W-4G can connect with up to 5 VPN servers.
†These functions are supported only in Standalone Mode.
§These functions are supported only in Controller Mode.
- Warranty Type
- Limited Lifetime Warranty
General
- Model
- ER706W-4G
- Form factor
- Desktop, Wall mount
- Data transfer speed
- 2,976 Mbit/s 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz
- Managed
- Yes Yes. Require the use of Omada Cloud-Based Controller.
- VPN Tunnels
- 50 pcs.
WiFi
- WiFi
- Yes
- WiFi Standard
- Wi-Fi 6
Ports
- WAN
- 1 pcs. Gigabit WAN Port
- LAN
- 4 pcs. Gigabit LAN/WAN Ports
- 4G
- Yes Nano SIM Card
- 5G
- No
- SFP Ports
- 1 pcs. Gigabit SFP WAN/LAN Port
Packaging info
- Packaging size
- 187 x 380 x 86 mm
- Packaging weight
- 1.62 kg
