The Yale Code Handle facilitates your own access and access control. With the Yale Code Handle, you can leave your belongings in the office for lunch without worrying about meeting participants having to drag their computers or other belongings with them during breaks. The Code Handle provides a simple solution for locking the doors to the office, regardless of time and place. For retail premises, Code Handle is an easy and cost-effective solution for restricting the movement of customers in break rooms, offices and warehouses. Similarly, schools can improve the security of their premises by installing a button, for example, on doors in supply rooms that would normally remain unlocked.
Please note, however, that the Code Handle is not suitable for use in outdoor areas or for locking main doors.
Examples of applications
- Offices and conference rooms
- Communal warehouses
- Back of store
- Break rooms
- Customer WC
- Home office
- "Staff only" facilities
Features:
- Keyless locking with code
- Automatic and manual locking function with key code
- Automatic and automatic automatic operation Automatic and manual operation Automatic and manual operation Automatic and manual operation
- Master code and nine user codes, 4 to 6 digits
- Sound and light signals indicate successful programming and locking
- After five incorrect attempts to open the door, the code is temporarily locked and prevents opening
- Battery change notification
- Easy installation - no wiring to the door
- Can be reset to factory settings
- Available in left and right hand versions
- Material: brushed RST/satin chrome plated zinc
Tested:
- EN 1906 Grade 2
- Tested over 100 000 openings according to EN 1906
- Knob testing 500 000 depressions
- Up to 60 000 openings with two CR2 3 V Lithium batteries
- IP40, for use on interior doors only
- Fire tested for 60 min., according to EN 1363
- 48 hours corrosion test
- EMC
- Torsion tested
NOTE: The push-button keys must not be wetted. Do not use wet cloth or strong solvents to clean the product. Clean the button with a lint-free cloth and, if necessary, a diluted detergent solution to avoid damaging the electronics of the product.
Two different models - same stylish appearance
Code Handle is available in two different models depending on the application. The Yale CHD 8811 is suitable for locking internal doors in private houses and is compatible with ABLOY external door lock frames 2014, 2011, 2018 and 2040.
The Yale CHD 8814, on the other hand, is a viable solution for locking interior doors in commercial buildings, typically used with the ABLOY 4190 and LC190 series lock bodies, as well as the ABLOY 4290 and LC290 lock bodies.
- Code lock for internal and external doors
- Keyless locking with code
- Automatic and manual locking
- Easy installation
- Model: 8811, right
